\n Description
\nThe brightest just got up to 69% brighter than our previous generation. The OnX6 + LED light bar also integrates Baja Designs’ trademarked High Speed Spot™ reflector, the same one used by our Team Enlightened racers, to give you the guaranteed furthest projecting LED Light Bar on the planet. In addition, the OnX6 + LED light bar adopts industry standard sizing and is now compatible with aftermarket mounting systems. An industry first 30 Day Satisfaction Guarantee & Limited Lifetime Warranty is included for the ultimate in purchase protection.
\nThis bar is equipped with BMT – Battery Management Technology
\n\n Specifications
\n| Width | \nLumens | \nWattage/Amps | \nDimensions | \n
|---|---|---|---|
| 10\" | \n(High) 12,460 (Low) 9,230 Utilizing 6 LEDs | \n(High) 108W / 8.4A (Low) 80W / 5.7A | \n10\" x 4.29\" x 2.69\" | \n
| 20\" | \n(High) 24,920 (Low) 18,460 Utilizing 12 Cree LEDs | \n(High) 216W / 16.6A (Low) 160W / 12.0A | \n20\" x 4.29\" x 2.69\" | \n
| 30\" | \n(High) 32,070 (Low) 25,610 Utilizing 18 Cree LEDs | \n(High) 278W / 21.7A (Low) 222W / 17.1A | \n30\" x 4.29\" x 2.69\" | \n
| 40\" | \n(High) 39,220 (Low) 32,760 Utilizing 24 Cree LEDs | \n(High) 340W / 26.8A (Low) 284W / 22.4A | \n40\" x 4.29\" x 2.69\" | \n
| 50\" | \n(High) 39,220 (Low) 32,760 Utilizing 30 Cree LEDs | \n355W / 28.2A | \n50\" x 4.29\" x 2.69\" | \n
- \n
- \nLED Life Expectancy:49,930 Hours \n
- \nFront Lens:Hard Coated Polycarbonate \n
- \nHousing:Aircraft Grade Aluminum w/Mil-Spec Hard Anodize \n
- \nBezel:Billet Machined Aluminum \n
- \nHardware & Bracket Material:Stainless Steel \n
- Exceeds MIL-STD810G (Mil-Spec Testing) \n
- Built-In Overvoltage Protection \n
- IP69K (Waterproof up to 9ft & Pressure Washable) \n
- IK10 Compliant (Mechanical Impact Testing) \n
\n What's Included
\n- \n
- OnX6+ LED Light Bar \n
- Mounting Brackets \n
- Hi-Low Dongle \n
*Please note that this light does NOT include a harness and the applicable harness to this light is 640119
\n\n Features
\n- \n
- Elimination Of Flickering at Low Voltage \n
- Added Protection to Vehicle Wiring and Systems \n
- Protection from Dangerous Current Spikes \n
- \nuService® – Replaceable Lenses And Optics \n
- \nClearView® – All The Light, Right Where You Need It. \n
- \nMoistureBlock™ – Waterproof, Rain Proof, Submersible \n
- \nCopperDrive® – Only LED Driven At 100% \n
- \n5000K Daylight – Less Driver Fatigue, Natural Color \n
\n Beam Patterns
\nDriving/Combo: Maximum trail coverage in a single light. The Driving/Combo pattern is equipped with both Wide Driving (42°) and the spot (6°) optics to provide you with a smooth blend of light for both near field applications and distance (Lighting Zone 3)
\nWide Driving: BD was the first to develop a pattern specifically for cornering, dust and/or fog conditions. The Wide Driving pattern offers a 42° flattened horizontal beam for the ultimate in comfort lighting. (Lighting Zones 1 & 2) (Also available in amber)
\nHigh Speed Spot: A longer and narrower 6° beam focus for illumination further down the trail or road. The Spot pattern is designed to be used in conjunction with additional Wide Driving and/or Driving/Combo beam lights. (Lighting Zone 4 & 5)
